Aeroflow Holden HQ HJ HX HZ WB 253 308 V8 Black Alternator 120 Amp Internal Reg

Aeroflow Stealth Black 120 Amp Internal Regulator Alternator
Suitable for Holden 253, 304, 308 V8 Engines as fitted to:

• HT HG HQ HJ HX HZ WB Holden
• LH LX Holden Torana
• VB VC VH VK VL VN VP VR VS Holden Commodore

This part is compatible with 135 vehicles

Specifications:

• Aeroflow AF4270-1120 120 Amp Black Alternator
• Electroplated black for a functional and durable finish
• Internal Regulator
• Can be used in either 1 wire or 3 wire hookup configuration
• Self exciting type alternator
• Huge 120 Amp output
• Factory load tested and certified before being packed
• Supplied and fitted complete with matching black alternator pulley
• 12 month warranty

Fitment Notes:

• Suitable to replace existing 1 wire, V-Belt type, internal regulator GM style alternator.
• Mounts measure approximately 18mm outside depth on the short side, 51mm outside depth on the long side.
• The measurement between the mounts from the inside edge, to inside edge is 159mm.
• The measurement between the mounts from the bolt centres is 6.60".
• Utilizes the the standard GM 10SI style case with 6.600” bolt centres.
• Total length from the front of the rotor shaft to the deepest point at the rear of the case is approximately 165mm.
• Please use the above measurements and information to compare to your original alternator, to ensure correct fitment for your vehicle.
