Pressure Range (psi): EFI 40 to 75psi
Regulator Style: Return type
Regulator Location: Inline
Boost/Vacuum Reference Port: Yes 1:1, Rising Rate, works on boosted applications
Gauge Port: Yes, 1/8 NPT front Port
Inlet Size: -10AN
Inlet Attachment: Female threads
Outlet Size: -10AN Return size: -10AN
Bypass Rate:550 LPH
Regulator Material: Aluminum, Anodised Black
Mounting Bracket Included: Yes
Raceworks fuel pressure regulators are designed to provide the correct fuel pressure for any high performance vehicle. They're available in a variety of configurations and pressure ranges for both universal and vehicle-specific applications.
